Shenzhen Blumoti Energy Co., Ltd. is a leading Chinese manufacturer and supplier of pouch u shaped lipo battery. If you are looking to source durable, bulk pouch u shaped lipo battery from China, feel free to contact our factory for details. Custom orders are welcome.

Pouch U Shaped Lithium Polymer Battery Manufacturer | Custom U Shaped Lipo Battery Supplier

Name: China Pouch U Shaped Lipo Battery Manufacturers, Suppliers and Factory - Wholesale Service - Blumoti
Brand: Blumoti
SKU: 289579244

A pouch U-shaped LiPo battery is a custom lithium polymer cell made with a flexible aluminum-laminate pouch and shaped to fit around internal components such as circuit boards, motors, or sensors.

Its U-shaped design helps use space that a standard rectangular battery cannot reach, making it a good choice for compact and irregular product layouts. With a slim, lightweight structure, it is commonly used in wearables, ultra-thin laptops, portable medical devices, and other space-limited electronics.

Pouch U Shaped Lipo Battery– General Specifications

Nominal Voltage: 3.7V

Charging Voltage: 4.2V

Discharge Cut-off Voltage: 3.0V

Nominal Capacity: 100mAh (0.2Cdischarge)

Standard Discharge Rate: 0.2C–1C; 1C-10C can be customized.

Standard Charging Rate: 0.2C–0.5C. max. 1C

Protection Circuit: PCB/PCM, including overcharge, over-discharge, overcurrent, and short-circuit protection

Operating Temperature: 0–45°C (charging); -20–60°C (discharging)

Product parameters

Model NO.	Capacity	Nom.Voltage	Discharge Rate	Thickness	Width	Length	Shaped
202726BM	110mAh	4.35V	1C	2mm	27mm	26mm	U Shaped
343023BM	150mAh	4.35V	1C	3.4mm	30mm	23mm	U Shaped
482327BM	250mAh	4.35V	3C	4.8mm	23mm	27mm	U Shaped
412726BM	300mAh	4.35V	1C	4.1mm	27mm	26mm	U Shaped
753427BM	750mAh	4.4V	1C	7.5mm	34mm	27mm	U Shaped

Pouch U Shaped Lipo Battery Features

Customizable Form Factor Besides U-shaped design, all other special shapes can be customized per your requirements.
Stable Discharge Voltage It maintains a steady voltage output during discharge, ensuring consistent and reliable device performance.
Long Cycle Life At 25°C ambient temperature, it retains 80% capacity after 600 charge-discharge cycles.

Applications for Pouch U Shaped Lipo Battery

1. Wearable Devices (Main Application)

Circular smart bracelets & sports watches: U/ring-shaped batteries utilize edge space bypassing internal motors and PCBs, serving as the standard form factor.
Neckband Bluetooth & bone conduction headphones: U-shaped batteries fit curved neck cavities for balanced comfort and battery life.
Smart rings & mini wearable sensors: Micro custom U-shaped batteries fit narrow ring inner spaces.

2. Laptops & Ultra-Slim Consumer Electronics

Ultra-thin laptops & 2-in-1 tablets: U-shaped batteries fill irregular edge space occupied by mainboards and heat sinks to increase capacity.
Foldable phones: Custom U-shaped batteries fit narrow corner spaces beside hinges, effectively boosting endurance.

3. Portable & Handheld Devices

Handheld POS terminals & barcode scanners: U-shaped batteries fit irregular spaces for compact body design.
Electric toothbrushes & handheld beauty devices: U-shaped batteries wrap around motors to make full use of handle cavity space.
Mini projectors & portable speakers: U-shaped batteries fill edge space to balance device size and runtime.

4. Medical Devices

Portable blood glucose & ECG monitors: U-shaped batteries fit irregular gaps between PCBs and sensors.
Hearing aids & cochlear implants: Micro U-shaped batteries suit curved cavities for product miniaturization.

5. Industrial & IoT Devices

Pipe/ring-type sensor nodes: U/curved batteries match ring-shaped inner cavities for power supply.
Handheld scanners & RFID readers: U-shaped batteries fit handle corner spaces to realize compact layout.
