Shenzhen Blumoti Energy Co., Ltd. is a leading Chinese manufacturer and supplier of 10C Discharge Rate Lithium Polymer battery Pack. If you are looking to source durable, bulk 10C Discharge Rate Lithium Polymer battery Pack from China, feel free to contact our factory for details. Custom orders are welcome.
Custom Lithium Polymer Battery Manufacturer | LiPo Battery Packs
A 10C 6S 6000mAh lithium polymer battery is a six-cell pack connected in series. It has a nominal voltage of 22.2V and is commonly used as a 24V-class power source, with total energy of about 133.2Wh.
With a 10C discharge rating, this pack can deliver up to 60A of continuous current. It is designed for stable power output and longer runtime, rather than extreme burst performance.
Typical applications include cruising drones, UAV platforms, robotics, portable power systems, inspection equipment, and other devices that need reliable 24V-class power with steady current delivery.
10C 6S 6000mAh Lithium Polymer Battery pack – General Specifications
Nominal Voltage: 22.2V
Charging Voltage: 25.2V
Discharge Cut-off Voltage: 18V
Nominal Capacity: 6000mAh (0.2C discharge)
Standard Discharge Rate: 10C (60A )
Standard Charging Rate: 0.2C–0.5C, max. 1C
Protection Circuit: PCB/PCM, including overcharge, over-discharge, overcurrent, and short-circuit protection
Operating Temperature: 0–45°C (charging); -20–60°C (discharging)
Product parameters
| Model NO. | Capacity | Nom.Voltage | Cathode | Thickness | Width | Length | Energy Density |
| BMP754445DT | 1800mAh | 22.2V | NCM | 45mm | 44mm | 45mm | 448 Wh/L |
| BMP574358DT | 1800mAh | 22.2V | NCM | 34.2mm | 43mm | 58mm | 468 Wh/L |
| BMP424870DT | 1800mAh | 22.2V | NCM | 25.2mm | 48mm | 70mm | 472 Wh/L |
| BMP505055DT | 1800mAh | 22.8V | NCM | 30mm | 50mm | 55mm | 497 Wh/L |
| BMP554448DT | 1800mAh | 22.2V | NCM | 33mm | 44mm | 48mm | 573 Wh/L |
Applications of 10C Discharge Rate Lithium Polymer battery Pack
Application Features
- Suitable for 6S / 22.2V voltage platforms
- Ideal for lightweight designs
- Suitable for applications requiring moderate continuous discharge current
- Not intended for high instantaneous burst current
- Better suited for runtime priority, stable output, and cruising operation
Typical Applications
- Fixed-wing aircraft / long-endurance airplanes
- Some large aerial photography drones, mapping drones, and inspection drones
- Some light-duty industrial drones
- Some portable custom equipment
- Prototype robots and competition robots
About Connectors and wires：
Connectors and wires can be configured based on the device application and actual current requirements.
For a 10C 6S 6000mAh lithium polymer battery pack, the maximum continuous discharge current is about 60A. A recommended configuration is AS150 or XT150 main discharge connector with 8AWG silicone wire, plus a JST-XH 7-pin balance connector for 6S balance charging. A high-current BMS can also be added if built-in protection is required.
For lower-cost applications, XT90 with 10AWG wire may be used, but it is more suitable for versions with actual continuous current around 45A or lower, rather than full 60A continuous discharge.
We provide what kinds of services
Flexible Customization:
Customize the shape, size, capacity, voltage, BMS, connectors, and more to fit your needs.
Supply Capacity:
Sample service available; bulk orders supported.
Comprehensive Service:
Reliable after-sales follow-up, and a one-year warranty.
Business Support:
OEM/ODM services available.
FAQ
Can you customize the dimension and capacity ?
Yes. the sizes can be customized, and the capacity can also be adjusted to a larger or smaller size.
Does the battery pack need a hard-shell protective case?
Hard-shell versions typically use a flame-retardant PC/ABS enclosure and can be integrated with BMS protection, making them suitable for applications that require stronger mechanical protection and higher safety.
Soft-pack versions are more commonly used in fixed-wing aircraft, drones, and other weight- or space-sensitive applications.
How long is the runtime?
The theoretical formula is:
Runtime (hours) = Battery capacity (Ah) ÷ Average discharge current (A)
For practical use, runtime is usually calculated at about 80% of rated capacity. Actual runtime also depends on the operating environment, internal wiring, and other losses.
Can you provide samples for testing?
Yes. Samples are usually available within 3–7 days.
